SKU:
50700
Availability:
Shoot, We've Run Out! Message Us Now For ETA & Alternatives!
2007-2013 GM 1/2 Ton Truck (2WD) 7"-9" Adjustable Lift Kit - McGaughys 50700
Applications-
- 2007-2013 Chevy/GMC 1500 Truck
- 2WD
Features and benefits-
- 100% bolt-on installation
- No cutting or grinding on the front or rear differential
- No re-routing of exhaust
- Lifetime warranty against manufacturer's defects on spindles
- No disassembling of the front struts (2007-2010) which is very time consuming
- Lift kit includes the lower A-frame support rods to prevent bending of A-frames
- All kits come in a brilliant, metallic silver powder-coat for longevity and durability
- Parts are CNC formed, machined, & laser cut in-house from the highest grade of materials so that every aspect of quality is obtained
- Spindles are CAD designed guaranteeing a perfect and accurate fit during installation and maintain stock alignment specifications
- The lower A-frame support rods and compression struts add extra support to prevent the front and rear crossmembers from flexing
This McGaughys Adjustable Lift Kit Includes-
- U-Bolts w/ hardware
- 6" Lift Blocks
- Rear Shocks
- Rear Crossmember Drop
- Rear Bump Stop Extenders
- Factory Strut Bushing Spacers
- Front Lift Spindles
- Hardware Pack
- Compression Strut Sleeves
- Front Brake Line Bracket Extenders
- CV Axle Spacers
- Compression Strut Bushings
- Compression Struts
- Lower A-Frame Support Rods
- Front Crossmember Drop
- Compression Strut Brackets
- Sway Bar Drops
- Sway Bar Extenders
- Lower Strut Extenders
- Skid Plate
- Upper Clam Shell Strut Extender
- Differential Drops
- Outer Tie-Rod Ends
Notes-
- Front Struts Can Be Set At 7", 8" or 9" using the ring adjuster on the lower coil spring mount
- McGaughys 7-9" Adjustable Lift Is a Full 7" Craddle Drop That Can Be Set To 8" Or 9" In The Front
- To Set at 9" You will Need To Order The Rear Add-A-Leaf by clicking HERE
- Lift Kit Instructions Click HERE
- Front Strut Instructions Click HERE
- McGaughys new 7-9" adjustable lift kits are able to be ran at a full 9" all the way around when you use an additional add-a-leaf. This can be purchased in addition to your kit or at any time by clicking HERE and simply add it to your cart!
Wheels & Tire Fitment-
- Minimum Wheel Diameter 17" x 8"
- Maximum Backspacing is 4 5/8"
- Stock Wheels Will Fit W/ Wheel Spacers
- 7-8" Lift Will Clear 20x9, 20x10 & 20x12 With 0mm to -24mm Offsets on 35" Tires (Also 18", 22" & 24" Wheels)
- 9" Lift Will Clear 20x9 & 20x10 with 0mm -12mm on 37" Tires (Also 18", 22" & 24" Wheels)
- 9" Lift Will Clear 20x12, 20x14 With 0mm to -44mm On 35" Tires (Also 18", 22" & 24" Wheels)
Track Width Changes-
- At 7" There Is No Track Width Change
- At 8" There Will Be About .25-.5" Track Width Change Per Side
- At 9" There Will Be About .75"-1" Track Width Changer Per Side
Fits-
- 2007, 2008, 2009, 2010, 2011, 2012, 2013 Chevrolet Silverado 1500 2wd
- 2007, 2008, 2009, 2010, 2011, 2012, 2013 GMC Sierra 1500 2wd
McGaughys Part # 50700
*** NO WARRANTY AT ALL ON POWDER COAT OR PAINT *** ONLY 1 YEAR WARRANTY ON ALL PARTS *** Spindles are lifetime *** McGaughy?s warrants all products manufactured by them against manufacturer?s defects in materials or workmanship for a period of one year from the date of original purchase. All McGaughy?s spindles carry a lifetime warranty against manufacturer?s defects. The warranty will not extend to any piece of merchandise or part there in, that has been improperly installed, abused, or neglected. Warranty is limited to the repair or replacement, at McGaughy?s discretion, after their inspection of the defective part, once returned to McGaughy?s with proof of purchase, date of purchase, and all shipping costs prepaid. Any cost of labor, freight, incidental or consequential damages are expressly excluded from this warranty. Check fit all products prior to custom painting or any form of fabrication (sanding, drilling, painting, chroming, etc.) McGaughy?s will not warranty any products that were modified prior to check fitting those parts on the intended vehicle. Call for technical assistance at (559) 226-8196 prior to modification if you are having any problems with your installation.
